UBD NOZZLES
Product parameters


Type: UBD-RA12/RA14/RA17/RA20/RA25(Max.1500bar)


UBD
Body Type
(O/D)

Head Type

Inlet Type

Flow Rate
(lpm)
@500bar

Flow Rate
(lpm)
@1000bar

Flow Rate
(lpm)
@1500bar

Inlet Thread
( FLUID Code)

Remark


UBD-RA12

(ø12mm)

2-Jets

Polisher

H12-2A

T12

(No Back Jets)


6

9

12

M8*1(3R)

M8 (4R)

M7 (2R)

1/4-28 LH (1L)

1/4-28 RH (1R)


Use with

Rigid Lance ONLY


H12-2B

8

13

16

H12-2C

11

16

21

H12-2D

14

20

26

H12-2A

T12-65

(With Back Jets)


14

20

25

Use with

Flexible & Rigid Lance


H12-2B

16

23

29

H12-2C

19

27

34

H12-2D

22

32

39

5-Jets

Universal

H12-5A


T12

(No Back Jets)

11

16

21

Use with

Rigid Lance ONLY


H12-5B

13

20

24

H12-5C

14

20

25

H12-5D

16

23

29

H12-5A

T12-65

(With Back Jets)

19

27

34

Use with

Flexible & Rigid Lance


H12-5B

21

31

37

H12-5C

T12-75

(With Back Jets)

25

37

45

H12-5D

27

39

48

UBD-RA14

(ø14mm)













2-Jets

Polisher






H14-2A

T14

(No Back Jets)



6

9

12

M8*1(3R)

M8 (4R)

M10*1 (7R)

1/8 BSPP (6R)

1/4-28 LH (1L)

1/4-28 RH (1R)

3/8-24 LH (5L)

3/8-24 RH (5R)







Use with

Rigid Lance ONLY



H14-2B

8

13

16

H14-2C

11

16

21

H14-2D

14

21

26

H14-2E

18

26

32

H14-2A

T14-65

(With Back Jets)



13

20

25

Use with

Flexible & Rigid Lance



H14-2B

16

24

29

H14-2C

19

27

34

H14-2D

22

32

38

H14-2E

26

37

45

5-Jets

Universal





H14-5A

T14

(No Back Jets)



11

16

21

Use with

Rigid Lance ONLY



H14-5B

13

20

24

H14-5C

14

20

25

H14-5D

16

23

29

H14-5E

19

27

34

H14-5A

T14-65

(With Back Jets)

19

27

34

Use with

Flexible & Rigid Lance



H14-5B

21

31

37

H14-5C

T14-75

(With Back Jets)


25

36

44

H14-5D

27

39

48

H14-5E

30

43

53

UBD-RA17

(ø17mm)
















2-Jets

Polisher








H17-2A

T17

(No Back Jets)




7

10

13

1/8 BSPP (6R)

3/8-24 LH (5L)

3/8-24 RH (5R)

M10*1 (7R)

1/4 NPT(9R)













Use with

Rigid Lance ONLY




H17-2B

9

14

17

H17-2C

12

17

22

H17-2D

15

22

27

H17-2E

18

27

33

H17-2F

22

32

40

H17-2A

T17-65

(With Back Jets)




15

21

26

Use with

Flexible & Rigid Lance




H17-2B

17

25

30

H17-2C

20

28

35

H17-2D

23

33

40

H17-2E

26

35

46

H17-2F

30

43

53

5-Jets

Universal








H17-5A

T17

(No Back Jets)

12

17

22

Use with

Rigid Lance ONLY




H17-5B

14

21

26

H17-5C

17

24

30

H17-5D

19

28

35

H17-5E

22

33

40

H17-5F

26

37

46

H17-5A

T17-65

(With Back Jets)

20

28

35

Use with

Flexible & Rigid Lance




H17-5B

T17-75

(With Back Jets)



25

37

45

H17-5C

28

40

49

H17-5D

30

44

54

H17-5E

33

49

59

H17-5F

37

53

64

UBD-RA20

(ø20mm)



















2-Jets

Polisher







H20-2A

T20

(No Back Jets)




7

11

13

M10*1 (7R)

1/4 BSPP (8R)

1/4 NPT(9R)

9/16-18 LH (10L)

9/16-18 RH (10R)



Use with

Rigid Lance ONLY




H20-2B

9

14

17

H20-2C

12

18

22

H20-2D

15

22

27

H20-2E

19

27

33

H20-2F

23

33

40

H20-2A

T20-65

(With Back Jets)




15

22

26

Use with

Flexible & Rigid Lance




H20-2B

17

25

30

H20-2C

20

29

35

H20-2D

23

33

40

H20-2E

27

38

46

H20-2F

31

44

53

5-Jets

Universal










H20-5A

T20

(No Back Jets)




12

18

22

Use with

Rigid Lance ONLY




H20-5B

15

22

27

H20-5C

17

25

31

H20-5D

20

29

35

H20-5E

23

33

41

H20-5F

26

38

47

H20-5G

30

43

53

H20-5A

T20-65

(With Back Jets)

20

29

35

Use with

Flexible & Rigid Lance





H20-5B

T20-75

(With Back Jets)

26

38

46

H20-5C

28

41

50

H20-5D

31

45

54

H20-5E

T20-85

(With Back Jets)

38

54

67

H20-5F

41

59

73

H20-5G

45

64

79

UBD-RA25

(ø25mm)





















2-Jets

Polisher









H25-2A

T25

(No Back Jets)




8

12

16

M10*1 (7R)

1/4 BSPP (8R)

3/8 BSPP (11R)

1/4 NPT (9R)

9/16-18 LH (10L)

9/16-18 RH (10R)

M20*1.5 (12R)

Use with

Rigid Lance ONLY





H25-2B

10

16

20

H25-2C

13

19

25

H25-2D

16

23

30

H25-2E

19

29

36

H25-2F

23

34

43

H25-2G

28

40

50

H25-2A

T25-65

(With Back Jets)




16

23

30

Use with

Flexible & Rigid Lance





H25-2B

18

27

33

H25-2C

21

30

38

H25-2D

24

34

43

H25-2E

27

40

49

H25-2F

31

45

56

H25-2G

36

51

63

5-Jets

Universal











H25-5A

T25

(No Back Jets)





13

19

25

Use with

Rigid Lance ONLY





H25-5B

15

23

29

H25-5C

18

26

33

H25-5D

20

30

38

H25-5E

24

35

44

H25-5F

27

39

49

H25-5G

30

44

55

H25-5H

34

50

62

H25-5A

T25-65

(With Back Jets)

21

30

38

Use with

Flexible & Rigid Lance






H25-5B

T25-75

(With Back Jets)


26

39

48

H25-5C

29

42

52

H25-5D

31

46

57

H25-5E

T25-85

(With Back Jets)



39

56

70

H25-5F

42

60

75

H25-5G

45

65

81

H25-5H

49

71

88
